Permanent Magnet Motor manufacturer made in china original with UL CE

SEMC produce durable and good quality PMAC motor permanent magnet motor permanent magnet dc motor . In permanent magnet ac motor and PMAC  motors, Rotor speed at the same speed as the motor's internal magnetic field. These type of motor are widely used in automobiles, toy industries etc. Please check specifications of special 90KW PMAC motor below:

DETAIL SPECIFICATIONS:

• Frame Size= 315S / M
• Power= 90 kW
• Number of poles= 16
• Frequency= 80 Hz
• Rated voltage= 380 V
• Nominal chain= 175 A
• Nominal rotation= 600 rpm
• Nominal conjugate= 1433 Nm
• Insulation class=  F
• Service factor= 1.00
• Moment of inertia (J)= 6.86 kgm²4
• Temperature elevation= 105K
• Duty= S1
• Room temperature= -20 ° C to +40 ° C
• Altitude= 1000 m
• Degree of protection=  IP55
• Cooling method= TFVE
• Constructive way= V3T
• Direction of rotation¹= Both
• Starting method= Inverter
• Approximate mass³= 1260 kg
• Power factor= 0.87-
• Operating limit with frequency inverter
• Peak phase-to-phase peak voltage <= 1600 V

Please contact us, If you want quotation or you want to know more about this special motor.
