Wire rod and steel belt type Strapping bundling machine for rebar beam pipe

• Metal strapper Bundling machine Main machine for rolling mill
• Fully automatic horizontal baler and coil finishing line system;
• Bar strapping machine and cooling bed, finishing collection system;
• Vertical baler and vertical core frame system;
• Structural steel strapping machine and cooling bed, palletizing system;
• High-speed wire rod rolling mill (pre-finishing mill, finishing mill, laying machine, shear group)
• Seamless steel tube rolling mill (piercing machine, continuous rolling mill, tension reducing machine)

• Double-channel bar packer
• Metal strapper Used to complete the binding and packaging of round steel, rebar, flat steel and angle steel.
• The baler is installed in a fixed position on the roller table
• Double-channel bar packer
• Bundling machine Tightening force of the bundle 9KN Wire specification 6.3-8mm
• Strapping machine Rod bundle size Φ150-450mm; Φ150-550mm; Valve voltage 21V Bundle wire material Steel wire Q195, Q235;
• Diameter of the inner ring of the line Φ700, Φ900;
• Motor power 11KW Bundling cycle 7s for single rao; 10s for double winding
• Hydraulic system pressure 100bar Pump capacity 100l/m

• Fully automatic circumferential baler
• Steel coil circumferential baler-side baler (single head/double head)
• Installed in the coiling exit or the occasion where the steel coil eye direction is the same as the conveying direction
• Bundling machine Suitable for coil width 550～2000mm, coil outer diameter 900～2250mm
• Strapping machine Packing conditions 1～3 pieces/1～5 pieces
• Steel coil circumferential baler-top baler
• Packing conditions 1～5 channels
•  Long product steel belt baler-top baler
• Metal strapper Suitable for online bundling of section steel, steel pipe, bar, etc.
• Using stack shape width 150～550mm
• Using stack height 150～600mm
• Adaptable design

• SEMC produce strapping machine bundling machine metal strapper and Take-up machine /recoiler
• Located at the end of the strip production line, it is used to wind the strip into a roll.
•  Use cantilever reel;
• The expansion and contraction of the reel is driven by a rotating hydraulic cylinder;
• EPC straight edge winding can be realized;
• Reducer adopts thin oil lubrication;
• Working temperature: 0~+120℃
• Conventional outer diameter of the reel: φ468, φ508, φ610, φ762
• Strip width: 2130 (Max)
• Normal maintenance cycle: 180 days/time

• Uncoiling machine Decoiler
• Located at the beginning of the production line, it is used to unwind the rolled strip. Use cantilever reel;
• The expansion and contraction of the reel is driven by a rotating hydraulic cylinder;
• With CPC centering function;
•  Reducer adopts thin oil lubrication
• Working temperature: 0~+120℃
• Conventional outer diameter of the reel: φ468, φ508, φ610, φ762
• Strip width: 2130 (Max)
• Normal maintenance cycle: 180 days/time

We produce strapping machine bundling machine metal strapper for steel strip in steel mill.

• Section steel baler
• Strapping machine Used to complete the strapping packaging of square bundles
• The baler is installed in a fixed position on the roller table, and the rod bundle passes through the closed line system of the baler while passing through the roller table.
• Patented top-mounted bundling head layout that deviates from the corner
• Patented drop-shaped wire groove
• Arrangement of anti-scratch rollers
• Tightening force 9KN
• Bundling specification 6.3-8mm
• maximum square bundle size is 1000X1000mm;
• the valve voltage is 21V;
• the bundle wire material: steel wire Q195, Q235;
• Bundling machine Effective line opening 1500X1300mm Motor power 11KW
• Bundling cycle 10s
• Metal strapper Hydraulic system pressure 100bar Pump capacity 100l/m
